Astrophotography > Cameras > Astronomical Cameras > ToupTek > EP3 > ToupTek Camera EP3-6300-KMA Deep Sky Mono
Product no.: 53644

Camera EP3-6300-KMA Deep Sky Mono

RRP: $ 369.00 Our price:
$ 349.00 incl. VAT plus shipping costs
too expensive?
long-term
Product not available anymore + lead time

Product description

The monochrome all-round camera for deep-sky objects and planets, with 6.4 MP resolution

The Touptek EP3CMOS06300KMA is a monochrome camera for deep sky and planetary photography. It is a 'universal talent' for any astronomical object that you would like to photograph. The sensor's 6.4 megapixel specification means you can use maximum resolution. Even higher image quality is achieved, unlike a colour sensor. This camera is suitable for all amateur astronomers who value seeing a wealth of detail in monochrome or who want to compose beautiful colour photographs using LRGB filters. The new back-illuminated sensor ensures higher photosensitivity and extremely low noise.

The advantages at a glance:

  • Highly sensitive and low-noise CMOS sensor
  • Rolling shutter for fast and brilliant images
  • Perfect for deep sky photography and guiding
  • High resolution and large image field: 3096x2080 pixels
  • 2.4μm - ideal for precise guiding

Included in the package - image acquisition and image editing software

Extensive software is included - with virtually everything an astrophotographer could wish for:

  • Live Image function
  • exposure settings
  • histogram
  • image acquisition and video functions
  • automatic Dark Subtraction
  • time-lapse image acquisition
  • image processing - stacking

Virtually everything you need is included in just one program, allowing you control of most of the image processing.

System requirements:

  • Windows 7, 8 or 10
  • Intel Core 2, 2.8GHz, 2GB memory, USB 2.0

Along with the camera, the drivers and cables required are included - to complete this convenient package.

Our expert comment:

Software download: TOUPTEK Software

Are you still looking for the right ToupTek camera?

- but don't really know which one you need? - selecting the right ToupTek camera is discussed in the blog article ToupTek - which camera is right for me? How to find out at a glance

(Marcus Schenk)

Specifications

Capacity


Sensor type
CMOS Chip (Sony IMX178)
Size of chip (mm)
7,37 x 4,92
Megapixel
6,4
Pixel size
2,4
Colour camera
no
Resolution Photograph (Pixel)
3096 x 2080
Bit depth (Bit)
14
Min. exposure time
244 µ
Max. exposure time (min)
16
Active cooling
no
Power supply
- (USB)
Interfaces
USB 3.0
Autoguider
no
Supported operating systems
Windows, Linux, Mac OSX
Connection (to the telescope)
T2 (M42 x 0,75)
Images per second
30 (at full resolution)
Software
included in product contents
Operating temperature
-10°C - +50°C/30-80%RH
Cable length (m)
1,5
Chip - Diagonal (mm)
8,86

Equipment


Filter wheel
no

General


Length (mm)
67
Diameter (mm)
39
Weight (g)
135
Series
EP3
Width (mm)
67
Height (mm)
39
Outer material
Aluminium

Area of application


Autoguider
no
Moon & Planets
yes
Nebulae & galaxies
yes
AllSky, Meteore
no

Product safety

Manufacturer: Hangzhou ToupTek Photonics Co., Ltd., 15F, Aoqiang Building 1, No. 6, Xiyuan 5th Rd., Hangzhou, 310030 Zhejiang, CN, www.touptek.com
Responsible person: NIMAX GmbH, Otto-Lilienthal-Str. 9, 86899 Landsberg am Lech, DE, [email protected]
