Microscopy > Microscopes > Inverted microscopes > Kern > OCO > Kern Inverted microscope Bino Inf Plan 10/20/40/20PH, HWF10x20, 30W Hal, OCO 255
Product no.: 66393

Inverted microscope Bino Inf Plan 10/20/40/20PH, HWF10x20, 30W Hal, OCO 255

$ 2,410.00 incl. VAT, plus shipping costs
too expensive?
short-term
ready for shipping in 1-2 weeks + lead time

Product description

  • The KERN is a robust, stable inverse microscope which is very easy to use, is ideal for all common routine applications, and which produces excellent images
  • As standard, these binocular microscopes are fitted with with large visual field , dioptre compensation and infinitely corrected planachromatic lenses
  • A revolving unit for up to lenses, an installed camera connection including a 0.5x C Mount Adapter and a kit for phase-contrast microscopy are also included with delivery as standard
  • Depending on the model, a large mechanical, adjustable or fixed specimen stage is fitted
  • The Abbe condenser with its aperture diaphragms and the large operating distance of 72 mm and fine adjustment with a division of 0.001 mm round off the characteristics of this high-quality microscope
  • The following optional accessory items are available: Various eyepieces, Lenses for a large working distance, a fixed specimen stageetc.
  • A central feature of this adaptable, robust inverse microscope range is the stable mechanism which can be adjusted precisely

For information on the accessories which are supplied as standard, please see the individual brochures for the models, see document downloads in the table

Specifications

Optics


Eyepiece
10x/20 (Widefield)
Optical system
infinity
Lens type
Plan, achromatic
Objective 1
LWD 10x
Objective 2
LWD 20x
Objective 5
LWD40x
Objective 3
LWD 20x PH
Magnification
100-400
Lamp type
Halogen (30W)
Power supply
EU-

Capacity


Brightness control
yes
brightfield
yes
Contrast methods
Phase contrast

Mechanics


Type of build
Trinocular
Viewing posture (°)
45 (45° angled eyepiece, 360° rotatable)
Focusing
Coarse and fine movement
Specimen stage
-

Special features


Filter holder
yes
Rechargeable battery operation
-
Dust cover bag
yes

General


Weight (g)
13500
Width (mm)
304
Length (mm)
599
Height (mm)
530
Series
OCO

Suitable for


Advanced
yes

Field of application


Education
-
Medicine
yes

Area of application


school
yes

Miscellaneous


supplier product number
OCO 255
