ZEISS 355 Lab
Versatile lighting for sample preparation
- Trinocular tube
- Integrated, nearly vertical lighting
- Double-arm gooseneck, self-supporting, for variable oblique illumination with distinct shadow effect
- Tiltable mirror base for bright field, dark field and oblique illumination
- ECO mode for easy switching to standby mode and back
- Type C input and output
- Optional: ergonomic hand rest, polarisation equipment for double spots and transmitted light
Microscope body Stemi 355 trino (item no.: 435066-9010-000)
- Greenough system
- c-mount camera output with fixed division 50vis : 50doc and permanently installed c-mount 0.5x camera adapter
- Manual, dual-sided zoom 5.5:1 (0.72x...4.0x) -
- Fixed zoom detent positions 0.72x-1x-2x-3x-4x
- Free working distance 110 mm
- Viewing angle 45° with adjustable eye relief 55...75 mm
- 30 mm eyepiece mount with maximum field of view 23 mm
- Mount D=76 mm for Stemi carrier/carrier S
- Interface D=66 mm for lights
- M52 thread for attachment optics or polariser
- Integrated, nearly vertical LED lighting (IVI) for tripods & mounts C Edu/Lab/Mat, tripod L LED, controller C
- Also included: 10x/23 Br. foc. eyepieces, RJ12 spiral cable
Tripod C Lab (item no.: 435426-9030-000)
- Stand base T331xW204xH89 mm
- Working area W209xD160 mm
- Interfaces d=84 mm for tables and d=46 mm for DL polariser
- Column 303 mm with drive and handle, stroke range 145 mm
- Stemi holder d=76 mm, load capacity 7 kg, adjustable friction
- 2x sockets for IVI and C LED light
- Separate AL/DL controls for on/off/dimming
- Switchover to ECO mode
- 2x USB-C ports for power input and output
- Integrated LED transmitted light unit with rotatable and adjustable mirrors for bright field, dark field and oblique transmitted light
- Built-in power supply 12V DC 24W/100...240V AC/50...60Hz
- Also included: glass plate + plastic plate b/w D=84x5 mm; dust cover
Double spot illuminator C LED (item no.: 435528-9010-000)
- Gooseneck double spot, 2x 160 mm for variable incident light illumination
- 2x M24x0.5 thread for polariser
- Height adjustable
- For tripods & mounts C Edu/Lab/Mat and L LED
Eyepiece cups (item no.: 444802-9000-000)
- Foldable eyecup with light protection
- to minimise disruptive light incidence -
- collapsible, can be used with glasses
