Telescopes > Meade > LX200 > Meade Telescope ACF-SC 254/2500 UHTC LX200 GoTo without Tripod
Product no.: 59593

Telescope ACF-SC 254/2500 UHTC LX200 GoTo without Tripod

RRP: $ 6,600.00 Our price:
$ 4,990.00 incl. VAT plus shipping costs
too expensive?
in stock
ready for shipping in 24 h + lead time

Delivery possible before Christmas (European destinations) - when you order by 18.12.!
Right of return up to January 31 2025!


Product description

More about the series LX200...

Meade’s LX200 is the most widely used advanced amateur telescope on Earth, and for good reason. It combines the most sophisticated optical system available with rock-solid mechanical and electronic elements to create the most versatile astronomical system available.

Sitting atop an ultra-stable tripod and mount, the LX200-ACF combines an amazing array of features: Primary Mirror Lock to eliminate focus and mirror shift during long exposures; large, high-quality worm-gear drives in both axes to provide extraordinarily smooth movement, and Smart Drive, delivering Permanent Periodic Error Correction (critical for long exposure astrophotography).

The LX200-ACF also comes with the AutoStar II handbox controller which puts over 140,000 objects at your fingertips and delivers the fastest GoTo performance available. This simple to use handbox provides complete control over every aspect of the telescope’s operation. You can even control the system from an external computer with supplied or third party software.

Advanced Coma-free Optics (ACF): Meade's ACF optical design eliminates the typical aberrations of all mirror optics. Thanks to ACF, the stars are also point-shaped right out to the edge of the image field, displaying no elongated comet-like distortions. The image field is flatter than that of classic Schmidt-Cassegrain telescopes. ACF optical systems show their strengths especially in astrophotographic applications.

Ultra-High Transmission Coatings (UHTC): This special multi-layer coating on the front correction plate provides up to 15% more light transmission. The result -brighter star clusters, finer details in nebulae and more surface detail on planets!

AutoStar II: Tour the Cosmos with Just the Push of a Button

The control of the telescope is through the AutoStar II system. Nearly all functions of the telescope are accomplished with just a few pushes of AutoStar II’s buttons. Because the AutoStar II system uses flash (rewritable) memory, your system will be able to grow when new features and enhancements become available.

Some of the major features of the AutoStar II system are:

  • Automatically move the telescope to any of the more than 145,000 objects stored in the object library. For example objects of the Messier Catalog, NGC Catalog and 227 named Objects.
  • Take a guided tour of the best celestial objects to view on any given night of the year.
  • Access a glossary of astronomical terms.

The AutoStar II handbox has soft-touch keys designed to have a positive feel. The LCD (Liquid Crystal Display) is backlit with red LEDs (Light Emitting Diodes) for easy viewing in the dark. The backlit display, key arrangement, and sequential menu structure make AutoStar II extremely user friendly.

Level North Technology - alignment is especially easy with this telescope. The signal from the built-in GPS receiver sends the computer controller the date, time and geographical location. Level North Technology adds information about the current orientation of the telescope. The telescope then automatically moves to from one to three stars (depending on the accuracy required). All you have to do is centre the stars in the eyepiece. This last step ensures that the accuracy of the alignment is successful.

It not only matters which telescope you buy but also where you buy it. Our additional services:

  • We are a leading telescope dealer and know the devices we sell. Our customer service team will gladly help you after your purchase if you have problems with assembly or operation.
  • We provide a copy of the 80-page Telescope ABC beginners handbook with every telescope.

Specifications

Optics


Type
Reflector
Type of build
ACF-Cassegrain
Aperture (mm)
254
Focal length (mm)
2000
Aperture ratio (f/)
9,8
Resolving capacity
0,45
Limit value (mag)
13,8
Light gathering capacity
1320
Max. useful magnification
510
Tube material
Aluminium
Coating
UHTC
Tube construction
Full tube

Reflector


corrector plate coatings
UHTC
secondary mirror design
hyperbolic
Main mirror´s construction
spherical
Ventilation for central mirror
no
Adjustable
yes

Focuser


Type of build
Internal
Connection ( to eyepiece)
2
Connecting thread (telescope side)
SC
Motorized
optional
Gear reduction
without

Mount


Type of build
LX200
GoTo control
yes
Mounting type
Azimuthal
Motors
Servomotors
Internal clock
yes
Cable-guide
internal
Power supply
12
Power consumption (mA)
5000
Battery compartment
yes
Battery life (h)
20

GoTo control


Database
145.000
GPS
yes
Software
AutoStar II
GoTo Language
English
WIFI
no
PEC correction
Meade Smart Drive
Tracking speeds
sidereal, Lunar, custom
Precision
1
Interfaces
AutoGuider, Aux, RS232
Hand Controller
AutoStar II
Alignment method
Level North Technology

Tripod


Type
without

Included accessories


Battery compartment
yes
1.25'' eyepieces
26mm
Deviating optics
1.25", 90° star diagonal
Finder scope
8x50

General


Series
LX200
Total weight (kg)
20,4

Area of application


Astrophotography
yes
Moon & Planets
yes
Nature Observation
no
Nebulae & galaxies
yes
Sun
no (Only with appropriate Sun filter)

Recommended for


Beginners
no
Advanced
yes
Observatories
yes

Miscellaneous


Battery type
Baby (C, LR14)
