Telescopes > TS Optics > Photoline > TS Optics Apochromatic refractor AP 130/910 ED Triplet Photoline 2,5"-OAZ OTA
Product no.: 51019

Apochromatic refractor AP 130/910 ED Triplet Photoline 2,5"-OAZ OTA

RRP: $ 2,580.00 Our price:
$ 2,350.00 incl. VAT plus shipping costs
too expensive?
long-term
Product not available anymore + lead time

Product description

This triplet apochromat is equipped with one of the best lenses in its class. The proven FPL53 from Ohara (Japan) is used as the apochromatic element. The colour-pure objective is mounted in a temperature-compensated mount that compensates for sub-zero temperatures. A solid metal tube and the Photoline RPA 2.5" deluxe focuser with rack and pinion adjustment make this apochromat a highly recommended instrument for the dedicated astrophotographer.

Your advantages:

  • Triplet lens with air gap
  • Temperature-compensated, fully adjustable mount
  • 2.5" RPA Photoline focuser with micro reduction gear
  • Direct thread connection for correctors and reducers
  • Sturdy tube with internal baffles

For astrophotography you should use a corrector. Two models are recommended here:

  • TS 2.5: The focal length is not changed, recommended distance from the M69 connection thread of the corrector to the camera sensor: 88mm
  • Reducer/Corrector Photoline 0.79x: The focal length is reduced to 719mm, recommended distance from the M48 connection thread of the corrector to the chip: 55mm

Both correctors can be screwed directly to the M68 connection thread of the focuser.

TS Optics is a brand of Teleskop-Service.

It not only matters which telescope you buy but also where you buy it. Our additional services:

  • We are a leading telescope dealer and know the devices we sell. Our customer service team will gladly help you after your purchase if you have problems with assembly or operation.
  • We provide a copy of the 80-page Telescope ABC beginners handbook with every telescope.

Specifications

Optics


Type
Refractor
Type of build
Apochromat
Aperture (mm)
130
Focal length (mm)
910
Aperture ratio (f/)
7
Resolving capacity
0,88
Limit value (mag)
12,4
Light gathering capacity
340
Max. useful magnification
260
Tube material
Aluminium
Tube weight (kg)
10,3
tube diameter (mm)
140
Coating
multiple
Tube construction
Full tube
lens design
Triplet

Focuser


Free aperture (mm)
63,5
Type of build
Gear rack
Connecting threaded socket (camera-side)
M68x1
Connection ( to eyepiece)
2
Load capacity (kg)
5
Rotating
no
Motorized
no
Gear reduction
1:10 fine focusing

Mount


Mounting type
no mount
GoTo control
no
Type of build
OTA

Included accessories


Dew Shield
yes
Prism rail
Vixen-Style
Tube clamps
yes
Eyepiece adaptor
2" / 1.25"
Corrector
without

General


Series
Photoline

Area of application


Astrophotography
yes

Recommended for


Beginners
no
Advanced
yes
Observatories
yes

Product safety

Manufacturer: Teleskop-Service Ransburg GmbH, Von-Myra-Straße 8, 85599 Parsdorf, DE, www.teleskop-express.de
